Hear from the people behind the Stumpjumper 15 in the introduction presentation. It’s a great overview of the bike and GENIE from mouths of the team who made them.
Watch NowOur full-suspension bikes are built to be relentless, desigend to endure years or hard riding, and backed by the best support and policies to keep ypu on the trail. Our unbeatable lifetime, no-questions-asked replacement suspension pivot bearings to the original owner (one bearing set, per bike, per year) is just one way we've got you covered. See your local Specialized Retailer for details.
Frame
M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
Seat Binder
Alloy, 38.6mm
SWAT
SWAT internal downtube storage
Rear Shock
FOX FLOAT Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/ LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm
Fork
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
Front Brake
TRP Trail EVO, 4-piston caliper, hydraulic disc, 203mm
Rear Brake
TRP Trail EVO, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 203mm
Shift Levers
Shimano SLX, M7100, 12spd
Rear Derailleur
Shimano SLX, M7100, SGS, 12-speed
Cassette
Shimano SLX, CS-M7100, 12-speed, 10-51t
Chain
Shimano SLX, M7100, 12-speed
Crankset
Shimano SLX, M7120, 32T ring, 55mm chainline, S1-S3:165mm, S4-S6: 170mm
Bottom Bracket
Shimano, BB-MT801, Threaded
Rims
Specialized, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
Spokes
DT Swiss Industry
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
Inner Tubes
Standard, Presta valve
Stem
Alloy Trail Stem, 35mm bar bore
Handlebars
Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise
Grips
Specialized Trail Grips
Saddle
Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
SeatPost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 190mm
Product ID
221397
Weight
16.17 kg (35 lb, 10.4 oz)
Weight Size
S4
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
S1 | S2 | S3 | S4 | S5 | S6 | |
---|---|---|---|---|---|---|
Crank Length | 165mm | 165mm | 165mm | 170mm | 170mm | 170mm |
Handlebar Width | 780mm | 780mm | 800mm | 800mm | 800mm | 800mm |
Stem Length | 40mm | 40mm | 40mm | 40mm | 40mm | 40mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 125mm | 150mm | 170mm | 190mm | 190mm | 190mm |
Stack | 608mm | 618mm | 627mm | 640mm | 654mm | 667mm |
Reach | 400mm | 425mm | 450mm | 475mm | 500mm | 530mm |
Headtube Length | 95mm | 100mm | 110mm | 125mm | 140mm | 155mm |
Headtube Angle | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° |
BB Height | 334mm | 337mm | 337mm | 337mm | 337mm | 337mm |
BB Drop | 41mm | 38mm | 38mm | 38mm | 38mm | 38mm |
Trail | 129mm | 130mm | 130mm | 130mm | 130mm | 130mm |
Fork Length (full) | 551mm | 561mm | 561mm | 561mm | 561mm | 561mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm | 44mm |
Front Centre | 720mm | 751mm | 780mm | 812mm | 843mm | 879mm |
Chainstay Length | 430mm | 432mm | 435mm | 435mm | 445mm | 445mm |
Wheelbase | 1149mm | 1181mm | 1213mm | 1244mm | 1285mm | 1322mm |
Top-tube Length (horizontal) | 541mm | 573mm | 595mm | 624mm | 647mm | 677mm |
Bike Standover Height | 738mm | 751mm | 745mm | 745mm | 745mm | 751mm |
Seat Tube Length | 385mm | 385mm | 405mm | 425mm | 445mm | 465mm |
Seat Tube Angle | 78° | 77° | 77° | 76.5° | 76.5° | 76.5° |
Saddle Height for Effective ST Angle | 645mm | 690mm | 735mm | 780mm | 825mm | 870mm |
Max Seatpost Insertion | 245mm | 245mm | 255mm | 255mm | 285mm | 285mm |
Min Seatpost Insertion | 80mm | 80mm | 80mm | 80mm | 80mm | 80mm |
