Specialized S-Works Tarmac SL9 Frameset (special order only)

Contact us in store or online via text and email to check availability on color and size. Framesets are special order only.

S-Works Tarmac SL9 Frameset

One Bike To Rule Them All

The all-new S-Works Tarmac SL9 is the fastest road bike ever made. Not just because it’s the lightest. Not just because it’s our most aero. Not because it handles better than anything else on the road. But because it delivers the lowest real-world Time to Finish of any road bike ever made. Tarmac SL9 turns more of your effort into pure speed—validated for real race courses, real terrain, real riders. When the goal is to cross the line first, no road bike gets you there faster.

At a Glance

Use

Road Racing

Frame

FACT 12r Carbon - 687 grams

Fork

FACT 12r Carbon

Headset

Ceramic Speed SLT

Seatpost

S-Works Rapide Post

Weight

1.39 kg

Technical Specifications

Frameset

Frame: S-Works Tarmac SL9 FACT 12r Carbon, Rider First Engineered, Win Tunnel Engineered, Ceramic Speed SLT headset bearings, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout

Suspension

Fork: S-Works FACT 12r Carbon, 12x100mm thru-axle, flat-mount disc

Cockpit

Seatpost: S-Works Rapide Post, FACT Carbon, 15mm offset

Seat Binder: Tarmac integrated wedge

Product details

Product ID: 293537

Weight

Weight: 1.39 kg (3 lb, 1.0 oz)

Weight Size: 56

Geometry

	44	49	52	54	56	58	61
Seatpost Length	300	300	300	380	380	380	380
Frame Stack	501	514	527	544	565	591	612
Frame Reach	366	375	380	384	395	402	408
Stack to Stem	509	522	535	552	573	599	620
Reach to Stem	363	372	377	381	393	400	406
Head Tube Length	99	109	120	140	157	184	204
Head Tube Angle	70.5	71.75	72.5	72.5	73.5	73.5	74
BB Height	266	266	266	268	268	268	268
BB Drop	74	74	74	72	72	72	72
Trail	71	63	58	58	55	55	52
Fork Length, Full	370	370	370	370	370	370	370
Fork Rake/Offset	47	47	47	47	44	44	44
Front Center	567	570	572	582	587	602	609
Chainstay Length	410	410	410	410	410	410	410
Wheelbase	970	973	975	986	991	1006	1013
Top Tube Length, Horizontal	496	509	531	540	563	577	595
Bike Standover Height	722	734	745	767	785	807	833
Seat Tube Length	433	445	456	473	494	515	545
Seat Tube Angle	75.5	75.5	74	74	73.5	73.5	73
