Specialized Diverge 4 Comp Alloy Sram Apex

Diverge 4 Alloy

The Ultimate Getaway Vehicle

Race-tuned. Adventure-approved. The Diverge 4 gravel bike in E5 Alloy is built for full-gas race days and off-grid epics. With Future Shock 3.0, our most responsive frame ever, massive tire clearance, and internal storage for the first time ever on an alloy bike, the best gravel bike in the world just got better. Chase the horizon—or your rivals—it’s built for both.

At a Glance

Use

Gravel Adventure/Race

Frameset

E5 Premium Alloy

Suspension

Future Shock 3.1

Drivetrain/Wheels

SRAM Apex Eagle 1x12 / DT G540

Storage

SWAT 3.0

Weight

Diverge Alloy Comp: 10.6kg

Technical Specifications

Frameset

Frame: Specialized Diverge E5 Premium Aluminum, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout

Suspension

Fork: Future Shock 3.1 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc

Brakes

Front Brake: SRAM Apex, Hydraulic disc

Rear Brake: SRAM Apex, Hydraulic disc

Drivetrain

Shift Levers: SRAM Apex

Crankset: SRAM Apex DUB Wide, 40t

Rear Derailleur: SRAM Apex Eagle 12-speed

Bottom Bracket: SRAM DUB BSA 68 Wide

Chain: SRAM NX Eagle, 12-speed

Cassette: SRAM PG-1210 Eagle, 11-50t

Wheels & tires

Front Wheel: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples

Rear Wheel: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples

Inner Tubes: Presta, 700x32-50mm

Front Tire: Tracer 700x45, Tubeless Ready

Rear Tire: Tracer 700x45, Tubeless Ready

Cockpit

SeatPost: Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware

Seat Binder: Alloy, 30.8mm

Saddle: Body Geometry Power Sport, steel rails

Stem: Future Stem, Comp

Handlebars: Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare

Tape: Supacaz Suave

Accessories

SWAT: SWAT 3.0 internal downtube storage

Product details

Product ID: 223512

Weight

Weight: 10.6 kg (23 lb, 5.9 oz)

Weight Size: 56

Geometry

	49	52	54	56	58	61
Crank Length	165	170	172.5	172.5	175	175
Handlebar Width	380	400	420	420	440	440
Stem Length	60	70	80	90	100	100
Saddle Width	155	155	143	143	143	143
Seatpost Length	350	350	400	400	400	400
Stack	563	578	592	610	634	659
Reach	365	374	387	400	412	425
Head Tube Length	90	104	116	135	161	187
Head Tube Angle	70	70.5	71	71	71	71
BB Drop	85	85	85	85	85	85
Trail	72	68	65	65	65	65
Fork Length, Full	391	391	391	391	391	391
Fork Rake/Offset	55	55	55	55	55	55
Front Center	604	613	626	645	665	686
Chainstay Length	430	430	430	430	430	430
Wheelbase	1019	1031	1041	1060	1081	1102
Top Tube Length, Horizontal	521	537	556	575	593	613
Bike Standover Height	700	725	754	779	805	832
Seat Tube Length	400	430	470	500	530	560
Seat Tube Angle	74.5	74	74	74	74	74
