Salsa Fargo GRX 610 1X Brass

Information
Reviews

Whether you dream of local overnighters or round-the-world epics, Fargo GRX 610 can help bring it to life. Its triple-butted steel frame and Cutthroat Carbon Deluxe fork create a comfortable-yet-durable ride that’s engineered for loaded touring on mixed terrain. Adjustable Alternator 1.0 Flat Mount dropouts let you tinker with wheelbase and ride feel, and cargo mounts galore give you the freedom to roam farther between resupplies. Shimano’s GRX 610 1 x 12 drivetrain is a smooth-shifting system with more enough gear range for climbing the Cordillera Blanca or capitalizing on tailwinds in Croatia. Fargo’s ride quality and adaptability make it a smart choice for a steel bikepacking bike — we know you’ll go far together.

Triple Butted CroMoly Tubeset

Salsa-designed, triple-butted, and frame size-specific seamless CroMoly tubing

Cutthroat Carbon Deluxe fork

With trail-taming compliance and abrasion-resistant plates in high-wear areas, the Cutthroat Carbon Deluxe fork is designed for the rigors of rides that cover multiple road surfaces in unpredictable conditions

Fargo Geometry

Designed as a drop bar mountain bike, optimized for fit with the Salsa Cowchipper or Woodchipper handlebars. Capable of handling everything from technical singletrack trails, two-track, gravel, and the occasional paved road. Predictable handling with or without a load. The bike to ride for multiple-surface excursions

Alternator 1.0 Flat Mount dropouts

Our renowned Alternator rear dropout grants you ultimate drivetrain versatility. Go geared or single speed, QR or thru-axle, freehub, Rohloff, or Gates Belt Drive. Fargo comes equipped with a Boost-spaced thru-axle plates that are compatible with flat-mount brakes and ready for a rack and fenders. Different plates may be required for other drivetrain setups. Alternator also lets you adjust your wheelbase: set them all the way forward for a shorter wheelbase that results in quick and nimble handling or set them back for more stability.

Belt Drive Compatible

Tested and certified for belt drive use

Multiple Wheelsize Versatility

The Fargo frame can accommodate 27.5+, 29″, 29+ wheels and tires (29+ only compatible with sizes Small to X-large). This makes for a highly capable bike that’s ready for any endeavor on just about any terrain.

Cargo-friendly

Designed for use with Salsa Alternator Plus Rack 135/142/148 in the rear. The fork is compatible with Salsa Down Under Rack or Anything Cage HD using the Three-Pack mounts.

Frameset

Frame: Fargo
Fork: Cutthroat Carbon Deluxe
Color: Brass
Rear Shock: N/A

Drivetrain

Front Derailleur: N/A
Rear Derailleur: Shimano GRX RX822
Cassette: Shimano Deore M6100 HYPERGLIDE+, 10–51t, 12-speed
Chain: Shimano Deore M6100 HG
Crankset: Shimano MT510, 34t
Bottom Bracket: Shimano BB52
Shifter: Shimano GRX RX610
Brakes and Rotors: Shimano GRX RX410, Shimano RT64 (Center Lock, 160 mm front and rear)

Components

Headset (Upper/Lower): FSA Orbit ITA
Stem: Salsa Guide
Handlebar: Salsa Cowchipper
Grips/Bar Tape: Anti-slip shock-proof
Seatpost: Salsa Guide
Saddle: DDK 255

Wheels

Front Wheel: Shimano TC500-15-B 15 x 110mm hub, WTB ST i25 TCS 2.0, 32h, 29"
Rear Wheel: Shimano TC500-MS-B 12 x 148mm hub, WTB ST i25 TCS 2.0, 32h, 29"
Tires: Teravail Sparwood, 29 x 2.2", 60TPI Durable casing, tubeless-ready

Weight

Complete Bike Weight: 12.59kg or 27.75 lbs (size Medium)

Frame Specs

Frame Construction: Triple-butted CroMoly Steel
Fork Construction: Carbon
Rear Dropout Configuration / Rear Derailluer Hanger: Alternator 1.0 Flat Mount
Rear Hub Spacing: 148mm; 142mm thru-axle or 135mm quick-release with Alternator Reduction Plates
Front Hub Spacing: 110 x 15 mm thru-axle
Rear Brake: Flat mount (160–180mm rotor)
Front Brake: Flat mount (160–180mm rotor), flat mount frame standard (35 mm thickness), 42 mm bolt length
Steerer Tube: 28.6mm, Tapered
Crown Race: 40mm
Stock Headset Upper (S.H.I.S.): ZS44
Stock Headset Lower (S.H.I.S.): EC44
Seat Collar: 32.0mm
Seatpost: 27.2mm
Dropper Compatible (Routing): No
Front Derailleur (Clamp): 148mm rear spaced: high direct-mount (29mm offset) with Problem Solvers bracket (FS1328) 142mm rear spaced: high direct-mount (26.5mm offset) with 34.9mm clamp Problem Solvers Bracket (FS1323)
Max Chainring (CL) [3]: 1x crankset: 36t max. Boost and 34t non-boost or 46t Gates Belt Drive Sprocket; 2x crankset: 42/28t max. Boost and Non-Boost
Bottom Bracket: 73mm BSA, threaded
Design Wheel/Tire Sizes: 29 x 2.2", 27.5 x 3.0"
Tire Clearance Frame [1]/[2]: 29" wheels: 41–76mm (1.6"–3.0") SM - XL; 41–66mm (1.6" - 2.6") XS 27.5" wheels: 47–76mm (1.85"–3.0") 26" wheels: 70–76mm (2.75"–3.0")
Tire Clearance Fork [1]/[5]: 29 x 3.0"
Rigid Fork Spec: 483mm axle-to-crown
Max Suspension Fork Length [4]: 506mm (100 mm travel)
Fork Offset: 51mm
Bottle Mounts Frame: XS: Two; SM–XL: Three
Bottle Mounts Fork: One set of Three-Pack mounts on each fork leg
Rack Mounts Frame: Yes
Rack Mounts Fork: Yes, low-rider compatible. Salsa Down Under rack recommended.
Fender Mounts Fork: No

Geometry

Size	XS	SM	MD	LG	XL
A. Effective Top Tube	520	540	565	590	620
B. Stand Over	690	732	778	821	859
C. Reach	350	364	368	385	409
D. Stack	594	615	643	671	690
E. Total Seat Tube Length	355.6	406.4	457.2	508	558.8
F. Headtube Length	90	110	140	170	190
G. Headtube Angle	68.5	69	69	69	69
H. Seat Tube Angle	74	74	73	73	73
I. BB Drop	70	70	70	70	70
J. BB Height	303	303	303	303	303
K. Chainstay Length	445–462	445–462	445–462	445–462	445–462
L. Fork Length Axle to Crown	480	480	480	480	480
M. Fork Offset	51	51	51	51	51
N. Wheelbase	1050–1067	1067–1084	1083–1100	1110–1127	1141–1158
Crank Arm Length	170	170	170	175	175
Handlebar Width	44cm	46cm	48cm	50cm	52cm
Recommended Rider Height	150cm–160cm	160cm–175cm	173cm–183cm	180cm–191cm	188cm–UP
Stem Length	60	70	70	80	80

Measurements based on:

A Salsa Firestarter Carbon fork which is equivalent to an average 100mm fork at 20% sag
A 29 x 2.25" tire measuring 746mm in diameter
Standover (P) measured vertically to top of toptube from a position 50mm forward of BB center
